KV-10

● Sensitivity: 97dB(dB SPL.1Watt@1m)

● Maximum SPL: 121dB continuous/124dB peak

Nominal Impedance (Nominal Impedance) : 8Ohms

● Rated Power: 250W AES/500W Peak

● Dispersion Angle (+/-8dB): 80°*70°

● Frequency response range (frequency (+/-3dB): 60-20000Hz

● Appearance size (W*H*D) : 340*525*306(mm)

● Net Weight: 13.1Kg
KV-12

● Sensitivity: 98dB(dB SPL.1Watt@1m)
● Maximum SPL: 124dB continuous/127dB peak
●Nominal Impedance (Nominal Impedance) : 6Ohms
● Rated Power: 350W AES/700W Peak
● Dispersion Angle (+/-8dB): 90°*60°
● Frequency response range (frequency (+/-3dB): 51-20000Hz
● Appearance size (W*H*D) : 370*580*374(mm)
● Net Weight: 20Kg
KX-08

● Sensitivity: 94dB(dB SPL.1Watt@1m)
● Maximum SPL: 116dB continuous/119dB peak
●Nominal Impedance (Nominal Impedance) : 8Ohms
● Rated Power: 150W AES/300W Peak
● Dispersion Angle (+/-8dB): 90°
● Frequency response range (frequency (+/-3dB): 85-18000Hz
● Appearance size (W*H*D) : 230*475*257(mm)
● Net Weight: 10Kg
KX-10

● Sensitivity: 95dB(dB SPL.1Watt@1m)
● Maximum SPL: 119dB continuous/122dB peak
●Nominal Impedance (Nominal Impedance) : 6Ohms
● Rated Power: 250W AES/500W Peak
● Dispersion Angle (+/-8dB): 90°
● Frequency response range (frequency (+/-3dB): 55-18000Hz
● Appearance size (W*H*D) : 295*555*340(mm)
● Net Weight: 15.7Kg
KX-12+

Power: 400W-800W
sensitivity: 97db(dB SPL.1Watt@1m)
impedance: 8Ω
Frequency response range (+/-3dB) : 50HZ--20KHZ
Appearance size (H*W*D):*398mm*573mm*370mm.
Net weight: 22.5KG/ piece.
KX-15+

Power: 500W-1000W(8Ω),
sensitivity: 99db(dB SPL.1Watt@1m)
impedance: 8Ω
Frequency response range (Frequency(+/-3dB) : 48HZ--18KHZ
Appearance size (W*H*D) :470mm*690mm*440mm
Net weight: 33.8KG/ piece
KF-10

● Sensitivity: 95dB(dB SPL.1Watt@1m)
● Maximum SPL: 120dB continuous/123dB peak
Nominal Impedance (Nominal Impedance) : 8Ohms
● Rated Power: 300W AES/600W Peak
● Dispersion Angle (+/-8dB): 70°*100°(HxV)
● Frequency response range (frequency (+/-3dB): 50-20000Hz
● Appearance size (W*H*D) : 300*533*340(mm)
● Net Weight: 15Kg
KF-12

Rated Sensitivity: 98dB(dB SPL.1Watt@1m)
Maximum SPL: 123dB continuous/126dB peak
Nominal Impedance (Nominal Impedance) : 8Ohms
Rated Power: 350W AES/700W Peak
Dispersion Angle (+/-8dB): 70°*100°(HxV)
Frequency response range (+/-3dB): 47-20000Hz
Appearance size (W*H*D) : 360*600*382(mm)
Net weight: 19Kg
KF-15

Rated Power :400W AES/800W Peak
Rated Sensitivity :99dB(dB SPL.1Watt@1m)
Frequency response range (+/-3dB):45-20000Hz
Dimensions (W*H*D) : 410mm*680mm*440mm
Net Weight: (Weight) 23.5KG
HF-08

Frequency response (+/-3dB): 65Hz-19KHz
Power Rating: 150W
Power Peak: 300W
Impedance: 8 Ohm
Sensitivity: 95dB W/M
Driver (Systemtype): 8"*1+1 "*1
Appearance size (W*H*D): 285*430*365mm
Net Weight: 10KG
HF-10

Frequency response (+/-3dB): 47.5Hz-18KHz
Power Rating: 200W
Peak Power: 400W
Impedance: 8 Ohm
Sensitivity: 93dB W/M
Driver (Systemtype): 10"*1+1 "*1
Appearance size (W*H*D): 351*500*317mm
Net Weight: 14KG
HF-12

Frequency response range (frequency (+/-3dB):45Hz-18KHz
Power Rating: 300W
Power Peak: 600W
Impedance: 8 Ohm
Sensitivity: 94dB W/M
Driver (Systemtype): 12"*1+1 "*1
Appearance size (W*H*D):397*570*365mm
Net Weight: 17.6KG
